Frames
Manufactured from lightweight, high tensile 1.5 mm thick ‘Rustec’ steel.
Adjust 2-Fit side expander system that offers up to 12mm expansion each side to the structural opening.
Self-adhesive P-seal provided as standard.
Various frame depths and styles are available.

Leaf
44mm door leaf thickness, fitted with an integrated astragal for added security. Comprising of 2 x 1.2mm ‘Rustec’ steel sheets, the leaf skins are mechanically interlocked and internally bonded, providing greater stability and protection against de-lamination.

Door Ironmongery
Grade 13 stainless steel, twin bearing template drilled butt hinges with integral high security dog bolts are fitted as standard with CE marking. Other hardware available.

Finish
Supplied inclusive of a powder-coated finish in a standard colour. Full range of RAL and BS colours available.

Options and Upgrades

• Manual and Electric Locking.
• Vision panels up to 610 x 1524mm.
• Louvre panels up to 610 x 1524mm.
• Variety of solid and glazed side and over panels.
• Up to 36dB acoustic rating.
• Up to 1.5 U-value W/M2K.
